Turn Engineering Hours Into Minutes.
Bridge the Gap Between 3D Design and the Shop Floor in Minutes, Not Hours.
Manual 2D drafting often causes delays and inefficiencies in engineering. While CAD designs have shifted to 3D, 2D technical drawings still serve as the main communication tool on the shop floor. AIDraft, developed by Prescient Technologies, is an AI solution that automates the conversion of 3D models into fully dimensioned, compliant 2D drawings.
Intelligent Features: The Science of AIDraft
One-Click Auto-Detection and View Placement
AIDraft understands the geometry and manufacturing requirements. With a single click of the Auto Detection button, it instantly identifies critical detail views, sections, and projections, placing them optimally on your company template.
Automated Dimensioning and Redundancy Filtering
AIDraft detects critical features—holes, slots, and surfaces. It then populates the drawings with manufacturing-critical annotations and GD&T, while automatically identifying and removing redundant dimensions to ensure a clean, professional layout.
Direct CAD & PLM Ecosystem Integration
Designed for Industry 4.0, AIDraft integrates with your existing ecosystem and CAD platforms (Siemens NX, PTC Creo, SolidWorks, Autodesk) via in-app plugins. Export production-ready data in PRT, DRW, SLDDRW, DWG, and PDF formats and also connect seamlessly to your existing PLM/PDM via API.
Ensure Compliance with Quality Standards
AIDraft automates generates clean, compliant drawings that can withstand rigorous audits and speed up the approval process. Whether your organization uses ANSI, ISO, or DIN, our AI enforces strict adherence to drawing standards to ensure consistency across global teams.
Business Impact: Why Automate Drafting?
Accelerate Time-to-Market
Cut down the drafting lifecycle from days to minutes. By automating the transition from 3D to 2D, you can release products to manufacturing faster.
Zero-Error Manufacturing
Manual drafting can create discrepancies between the 3D model and the 2D print. AIDraft ensures that the drawing is a mathematical derivative of the model, which eliminates interpretation errors and costly scrap.
Optimize Engineering Resources
Your senior designers should be solving complex engineering and product challenges, not arranging viewports. Free your talent to focus on high-value generative design and optimization tasks.
Engineered for Complex Industries
Automotive
Automate 2D drawing generation for intricate engine components, chassis structures, and sheet metal parts.
Aerospace
Ensure strict adherence to GD&T for turbine blades and fuselage components where precision is non-negotiable.
Heavy Machinery
Rapidly generate drawings for large assemblies and bespoke tooling without the lag of manual detailing.
Hi-Tech
Rapidly create compliant 2D drawings for high-tech product development, supporting intricate components and premium manufacturing standards.
AIDraft Workflow
Input
Open your 3D CAD model in your favourite CAD software.
Process
AIDraft plugin analyzes feature topology, manufacturing intent, and organizational standards.
Generate
The system produces a fully layered, dimensioned, and compliant 2D drawing file (DWG, SLDDRW, PDF, DXF, etc.)
Review
Engineers perform a final check and required changes quickly, reducing review cycles.
Why Choose AIDraft by Prescient Technologies?
Prescient Technologies has a 25-year legacy in providing CAD/PLM solutions. Choosing AIDraft means partnering with a company that has deep roots in Knowledge Based Engineering (KBE) and software development. AIDraft utilizes Prescient’s background in geometric modeling and solid modeling to ensure that generated drawings maintain the exact tolerances required for the shop floor.
We understand that a drawing tool cannot exist in a silo. AIDraft is designed to fit into a broader Digital Factory ecosystem. Our approach involves "co-creating" solutions, meaning AIDraft can be adapted to specific industry verticals, from automotive to heavy machinery, ensuring compliance with organizational formatting and GD&T standards.
Ready to Automate Your Engineering Workflow?
Experience the power of AIDraft firsthand. Let our experts show you how AI can transform your design transition from a manual chore into a strategic advantage.
Get a Free ConsultationContact Us
Our experts will respond within 24 hours.
Which global standards does AIDraft support?
AIDraft supports all major international and national standards, including ISO, ANSI/ASME, and DIN.
Is AIDraft suited for highly regulated industries?
Yes, AIDraft is ideal for Aerospace, Automotive and Medical sectors. It provides the precision and documentation traceability required for AS9100 and ISO 13485 compliance.
Can I use my own company-specific templates?
Yes. AIDraft automatically adapts to your internal templates, title blocks, and annotation styles.
Does AIDraft work with my current CAD software?
AIDraft features direct plugins for Siemens NX, SolidWorks, Autodesk Inventor, and others, supporting various export formats like DWG, DXF, IDW, and PDF.
